Yamaha YZF-R1 | Racecourse Motors Sydney

Refined CP4 Engine

The YZF-R1 come equipped with the next generation of Yamaha’s unique 998cc inline four-cylinder crossplane crankshaft engine for refined performance. Returning features such as titanium fracture-split connecting rods and offset cylinders contribute to a responsive and potent character, while the cylinder head, fuel injectors, finger-follower rocker arms, and camshaft profiles are new for 2020.

Advanced Bodywork

Redesigned bodywork contributes to higher-quality performance and a more comfortable rider fit. The new design creates a 5.3% increase in aerodynamic efficiency while reducing wind noise and pressure on the rider when in a tucked position, and improved comfort comes from smoother side sections where the rider’s legs contact the bike.

Brake Control System

Technology is transforming the way we ride, and the latest YZF-R1 features no fewer than seven electronic control systems. Featuring two modes, the new Brake Control (BC) system analyses data such as lean angle and slipping acceleration and modulates hydraulic brake pressure to prevent wheel lock ups.

Engine Brake Management

Control is everything when you're on the track, and the new Engine Brake Management (EBM) system allows you to adjust engine braking force. Using data from various sensors, the EBM adjusts throttle opening, ignition timing and fuel injection volume to give you a choice of three engine braking modes to suit different riding situations.

Enhanced Suspension

The 2020 YZF-R1 receives suspension performance enhancements courtesy of a new KYB front fork with a new internal shim stack design, and a KYB rear shock with revised internal settings. Together, the changes result in smoother suspension dampening paired with an improved feeling of contact and grip with the street or track surface.

Quick Shift System

The YZF-R1 also comes equipped with a new Quick Shift System that gives faster gear changing. This system instantly cancels drive torque when an upshift is detected - enabling full throttle clutchless upshifts for outstanding acceleration through the close ratio 6-speed transmission.

6-Axis IMU

The 6-axis Inertial Measurement Unit (IMU) consists of a gyro sensor (angular velocity sensor) that constantly measures machine pitch, roll and yaw, and a G-sensor (accelerometer) that measures acceleration in the forward-backward, up-down and right-left directions. This technology makes possible the class-leading array of rider aids includes lean sensitive Traction Control System (TCS), Slide Control System (SCS) as well as a front wheel lift control system (LIF) and Brake Control system (BC).

Accelerator Position Sensor

An all-new Accelerator Position Sensor with Grip (APSG) ride-by-wire system- featuring Yamaha’s Chip Controlled Throttle (YCC-T) - eliminates throttle cables and reduces weight while providing smoother throttle operation.

LED Headlights

New lightweight, compact LED twin headlights for both the low and high beam, combined with the redesigned body styling to create a new front face symbolising the next-generation of R-Series design.

Engine

Engine Type: Liquid-cooled, 4-stroke, DOHC, 4-valve, forward-inclined parallel 4-cylinder

Displacement (cc): 998.0

Bore x Stroke (mm): 79.0 x 50.9

Compression Ratio: 13.0 : 1

Lubrication System: Wet sump

Fuel Management: Fuel Injection

Engine Management: YCC-T, YCC-I, SCS, LIF, UBS, ABS, LCS

Ignition: TCI

Starter System: Electric

Fuel Tank Capacity (L): 17.0

Final Transmission: Chain

Transmission: Constant mesh 6-speed

Chassis

Frame Type: Aluminium Deltabox

Suspension Front: Telescopic forks, 120mm travel

Suspension Rear: Swingarm (link suspension), 120mm travel

Brakes Front: Hydraulic dual discs, 320mm - ABS

Brakes Rear: Hydraulic single disc, 220mm - ABS

Tyres Front: 120/70 ZR17MC (58W) Tubeless

Tyres Rear: 190/55 ZR17M/C (75W) Tubeless

Dimensions

Length (mm): 2055

Width (mm): 690

Height (mm): 1165

Seat Height (mm): 860

Wheelbase (mm): 1405

Ground Clearance (mm): 130

Wet Weight (kg): 201
